MIL-DTL-16356E
3.14.3 Clamping device. The frame of reflex gauges (except welding pad design) shall be clamped to the cover
by U-bolts, the U-bolts extending through the cover and retained by nuts. Means shall be included in the frame or
cover to retain the U-bolts in position when the cover is removed. Bolting used in all Type C designs shall be in
accordance with 3.12.10.b requirements.
3.14.4 Glass. Refer to requirements of 3.12.3 or 3.13.1.1 as applicable for glass requirements. Replacement
transparent glass shall be suitable for HP service regardless of pressure rating of Type C indicator.
3.14.5 Gaskets. Two gaskets of 1/16 or 1/32 inch thickness shall be furnished with each glass unless otherwise
specified (see 6.2). The outside dimensions of the gaskets shall be the same as those of the glass for which they are
intended. The bearing surface of the gasket shall have a uniform width of not more than 3/8 inch and not less than
/16 inch. Type C indicators may use a variety of gaskets based on the fluid service, in accordance with Table V. In
5
addition to those listed below, the MIL-DTL-24696, Type I and II gaskets supplied with Type A and B gauges may
be selected. Type II gaskets can be used in steam service up to 150 psig per 366 °F, water service up to 400 psig per
300 °F, lube oil system up to 150 psig per 250 °F and hydraulic or other petroleum based oil systems up to 600 psig
per 180 °F. Where detrimental material requirements of MIL-DTL-24777 apply, special test requirements in
addition to those listed in the line callouts are required.
TABLE V. Alternative gasket material.
Commercial Name/
Thickness
Description - Binder
ASTM F104 Line Callout
MIL-SPEC (Cage Code)
(Inch)
Non-asbestos fiber-composite
Thermo-Tork® TN-9004 (Interface
/16
1
elastomer - aramid - Nitrile
F729100E33M9
Solutions Inc., Lancaster, PA) or equal
Butadiene Rubber (NBR)
Non-asbestos fiber -
/16
1
composite elastomer - aramid
IFG®-5500 (73680) or equal
F712103A9B4E23L501M4
- NBR
Polytetrafluoroethylene
/16
1
Gylon® 3500 - Fawn (73680) or equal
F452111A9B4E11M5
(PTFE) with silica
PTFE with glass micro
/32 or 1/16
1
Gylon® 3504 - Blue (73680) or equal
F456111A9B7E11M6
spheres
/16
1
MIL-R-3533 Type II, Grade A
Buna-N
N/A
/16
1
MIL-DTL-25988 Type I, Grade 70/1
Fluorocarbon
N/A
Ethylene Propylene Rubber
/16
1
MIL-DTL-22050 Grade 1
N/A
(EPR)
/16
1
MIL-PRF-6855F Class 1, Grade 60
NBR
N/A
3.14.6 Material. Material that does not conform to an ASTM grade shall not be used in pressure containing,
high stress, or cyclic stress applications. Type A requirements of 3.6 apply to hardware.
3.14.7 Valves. Type C valves shall be rated for either 150 psig or 300 psig to match the rating of the boiler or
tank flanges. Drain valves that are part of the welded assembly formed with the lower gauge isolation valve shall be
bolted bonnet-type. Gauges for waste heat boilers shall have bolted bonnet shut-off valves. The quantity, type, and
size of drain valves shall be as specified (see 6.2).
3.14.8 Shock. When specified, gauges shall be in accordance with the Type C shock requirements of
3.14.9 Vibration. When specified, gauges shall be in accordance with the Type I vibration requirement of
20
